Troubleshooting Radiators: 6 Steps
What to do if your radiator is hot at the top and cold at the bottom
Via Boiler Central
With colder weather on the horizon and rising inflation rates that are affecting every day costs of living, experts at Boiler Central have shared a few tips on how to fix a cold radiator and what may be causing this problem.
Radiators have an important job of keeping the house warm. So, when a radiator is cold at the bottom, something’s not right. Most likely, it is not functioning properly, which could lead to more complicated issues.
If a radiator has cold patches while the heating is on, it could mean that there is sludge present inside the radiator. Sludge tends to accumulate inside the radiator over time. Once enough sludge is in the radiator, it blocks the flow channels, meaning water is unable to move around the radiator effectively.
“Unfortunately, radiator sludge is a very common occurrence and this is because of the reaction caused when water interacts with metal,” said a spokesperson for Boiler Central. “When this happens, the best thing you can do is clean the radiator completely.”
Luckily, this is a very common issue and there are simple steps to clean a radiator and prevent sludge buildup.
Six Steps to a Better Boiler
Cleaning a radiator to get rid of the cold spot at the bottom:
1. Isolate the radiator.
- If the affected radiator has a thermostatic radiator valve, turn this down to 0. On the other side of the radiator is a valve known as the lockshield valve (covered with a plastic hood).
- Close the lockshield valve using a spanner — this may be either a quarter or half a turn but take note of this, as it will be how much it needs turning to open it back up again. Wait at least an hour for the water in the radiator to fully cool.
2. Set up for leaking water.
Looking for quick answers on air conditioning, heating and refrigeration topics? Try Ask ACHR NEWS, our new smart AI search tool. Ask ACHR NEWS
- Have some containers or buckets on hand to ensure that you catch all the water that escapes from the radiator without overflow or spillage. Place an old rag under each vale to ensure any unexpected leaks don’t ruin the flooring.
3. Open the bleeding valve.
- Open the bleed valve right at the top of the affected radiator using a bleed key or a screwdriver. Water will then begin pouring out from the loosened nuts.
4. Remove and clean the radiator.
- When the water stops coming out of the radiator, disconnect the valves and take the radiator off its bracket. Ensure not to completely undo the valves, as this could cause the contents of your heating system to empty.
- Take the radiator outside to clean. Attach a hose to one end of the radiator and blast water through the end for a couple of minutes until the water begins to flow clean. To ensure that the radiator is completely clean, connect the hose to several different openings.
5. Test out the system.
- Once done, place the radiator on its bracket. Ensure the pipes are attached to the nuts while turning the valves in either end to their original positions.
- Water will begin refilling the radiator, so you must have the bleed key on hand. Close the bleed valve when water starts to escape from it.
- Once this is done, turn the heating back on and wait for around 30 minutes. If done properly, there should be no cold patches present on the radiator.
6. Re-pressurize.
- Once a radiator is removed from a sealed heating system, it must be re-pressurized. If the heating system is pressurized, add more water to the loop to level out the pressure.
