The Basics of 20 mA Control
Understanding electrical controls
Back in the “good old days,” controls were all analog and mechanical, which simply means that they acted in a directly connected and variable manner based on a change in force. Both pneumatic (air pressure) or hydraulic (fluid pressure) systems are examples of mechanical, analog controls. When pressure increased or decreased on a particular device it signaled a change in action on another device like a pump/valve etc.
In the HVACR industry, we still see these types of controls, with a TXV being a common example. The TXV is controlled by pressures in the suction line, bulb, and spring to set the outlet superheat. These forces are all mechanical without electrical inputs or specific data points. The feedback from these forces is in constant tension to output the proper amount of refrigerant to properly feed the evaporator coil.
Digital vs. Analog
As controls have changed from mechanical to electrical we now have systems that are controlled by analog electrical signals and digital electrical systems. Analog is simply a varying electrical signal (either voltage or amperage) that signifies changes in a system or device. A digital signal means data encoded into digits, which can be communicated using many different computer languages, rules, or protocols (these all mean essentially the same thing). In digital controls, the “signal” can include a combination of voltage, amperage, and On/Off changes to communicate between devices.
So what about 4-20 mA?
When the industry started to change over from mechanical to electrical they created a protocol (set of rules) that controls could use that would still function in a similar way to the old pneumatic controls. They decided that the range would be 4 mA(milliamps) as the bottom reference of any sensor and 20 mA would be the top reference. If you were setting up a sensor to indicate the fluid level in a tank you would set the bottom output to 4 mA (meaning empty) and the top output to 20 mA (meaning full).
In the case of a pressure transducer, you set the top range to the max rating of the sensor to 20 mA and the bottom pressure reading to 4 mA… you get the point.
mA controls are great because of their simplicity and ruggedness. You supply power to a sensor (a sensor/transmitter to be exact) and based on the measurement the sensor reports to the transmitter that produces a milliamp signal. This signal is connected to an input on the control that measures the amperage and converts that to a reading.
Because amperage is the same at all points in the circuit, the 4-20 mA circuit is not impacted by voltage drop or interference like a voltage sensing circuit. Because the “bottom” of the scale is 4mA, the control can also sense the difference between an “out of range” condition below 4ma and an open circuit.
Looking for quick answers on air conditioning, heating and refrigeration topics? Try Ask ACHR NEWS, our new smart AI search tool. Ask ACHR NEWS
The downside of a 4-20 mA control is that each device requires it’s own conductor. In digital controls, many devices can be controlled by a single conductor set or “trunk,” making it much easier to route, configure, and manage complex controls.
Testing 4-20 mA Circuits
There are two different ways to measure milliamps. One is to use a special milliamp clamp called a “process clamp meter” that allows reading the amperage without disconnecting wires. These meters are expensive and it is unlikely that a typical HVACR tech will have one.
The more common way is to use alligator clips on a quality meter set to the milliamp scale and connect in series with the circuit. This means you will need to disconnect a wire or terminal and put your meter in the path. This is the same way we test microamps on a gas furnace flame sensing rod, only using the milliamp scale.
