Passive Constant Airflow Regulator Networks for Multi-Tower High-Rise Ventilation Balancing
Empirical field outcomes from a 758,600 sq. ft. development in Brooklyn, New York
CAR: Writing about Neptune Towers in Brooklyn, New York, author Tarang Patel, Lead Mechanical Engineer at TRV Mechanical Contractors, highlights the three-tower residential development where passive Constant Airflow Regulator (CAR) technology helped achieve balanced ventilation, improved energy performance, LEED Silver certification, and Local Law 97 compliance.
Ventilation balancing across multi-tower high-rise residential developments presents a persistent engineering challenge: pressure variations between towers at different stages of construction, occupancy, and seasonal thermal loading create dynamic imbalances that electronically controlled systems must continuously correct at ongoing energy cost. This paper presents a field case study of a passive ventilation balancing strategy applied to Neptune Towers (532 Neptune Avenue), a 758,600 square foot, three-tower residential development comprising 499 apartments in Brooklyn, New York. The strategy employed factory-calibrated Constant Airflow Regulator (CAR) devices, passive, spring-actuated, pressure-responsive elements requiring no electrical input, no sensors, and no ongoing calibration, as the primary ventilation balancing mechanism across all three towers. Each CAR device maintains design airflow within plus-or-minus 5 percent of its factory-set value across a broad operating pressure range, providing passive self-correction to dynamic pressure variations without active control systems. Documented field outcomes, published by eFlow USA as an industry benchmark case study, include a 25 percent reduction in HVAC-related energy waste relative to a conventionally balanced active system, LEED Silver certification achievement, and New York City Local Law 97 carbon compliance across 499 apartments. The passive CAR architecture is presented as a scalable, low-maintenance alternative to electronically controlled ventilation balancing for multi-tower high-rise residential construction.
Introduction
Achieving consistent, code-compliant ventilation rates across large multi-tower residential developments represents one of the more technically demanding challenges in urban high-rise mechanical engineering. Unlike single-tower buildings, where a single centralized ventilation system can be commissioned and balanced as a unified network, multi-tower developments present unique pressure dynamics: construction schedule offsets between towers, different occupancy profiles, varying solar loading on different tower orientations, and wind-driven pressure differences all create conditions in which a system balanced at one tower under one set of conditions will be out of balance at another tower or under different seasonal loads [1].
The conventional response, electronically controlled variable-air-volume (VAV) dampers with pressure sensors and building automation system (BAS) integration, provides continuous active correction but at significant cost: first-cost premium for sensors and controls, ongoing energy consumption by the control actuators, maintenance costs for sensor calibration and damper motor service, and the persistent risk of control system failures creating code-non-compliant ventilation conditions [2].
Constant Airflow Regulators (CARs) offer a passive alternative: a spring-actuated mechanical device that self-adjusts its open area in response to duct pressure variations, maintaining a factory-calibrated airflow rate within a specified tolerance band without any electrical input [3]. This paper presents the engineering design rationale and field outcomes of a large-scale CAR deployment across three simultaneous high-rise towers at Neptune Towers in Brooklyn, New York.
Background: Constant Airflow Regulator Technology
A Constant Airflow Regulator is a passive mechanical device designed to maintain a constant volumetric airflow rate within a specified tolerance band (typically plus-or-minus 5 to 10 percent of factory-set value) across a range of operating static pressures [3]. The device consists of a spring-loaded moveable element mounted within a cylindrical housing: as duct static pressure increases, the spring compresses and the element moves to reduce the effective open area, maintaining constant airflow; as pressure decreases, the spring extends to open the element and restore design flow. The device requires no power supply, no sensor inputs, no actuator motors, and no control logic.
Factory calibration sets the target airflow at manufacture, ensuring each device delivers its design rate across the manufacturer-specified operating pressure range without field adjustment. This characteristic makes CAR devices particularly well-suited to applications where duct pressure varies dynamically such as multi-tower developments with staged construction schedules or buildings subject to significant wind-driven envelope pressure variations [4].
Project Description
Neptune Towers (532 Neptune Avenue, Brooklyn, New York) is a three-tower residential development comprising a total of 758,600 square feet and 499 residential apartments. The development targets LEED Silver certification and full compliance with New York City Local Law 97, which establishes carbon emission limits for large buildings with graduated penalties beginning in 2024. TRV Mechanical Contractors LLC executed the mechanical HVAC scope.
HVAC System Configuration
The primary HVAC system comprises 582 Mitsubishi City Multi Variable Refrigerant Flow (VRF) indoor units and 527 VRF condensers, providing individual thermal control for all 499 apartments across the three towers. Ventilation is provided through a network of Energy Recovery Ventilators (ERVs) and CAR-regulated exhaust and supply air paths. Approximately 233,000 linear feet of refrigerant piping connects indoor and outdoor VRF components across the three towers, coordinated through a Navisworks Zero-Clash BIM workflow to prevent field installation conflicts.
Passive CAR Deployment Strategy
Factory-calibrated eFlow Constant Airflow Regulators were specified in two configurations: 4-inch diameter units factory-set at 25 CFM for bathroom exhaust applications, and 5-inch diameter units factory-set at 65 CFM for kitchen exhaust and supply air applications. CAR devices were installed at the terminal point of each exhaust and supply branch throughout all three towers, providing passive flow regulation at each apartment connection point without the need for electronic balancing, pressure sensors, or post-installation balancing contractor work.
Results and Discussion
The passive CAR ventilation network achieved a documented 25 percent reduction in HVAC-related energy waste relative to conventional active balanced system performance, as measured and published by eFlow USA in an independently produced field case study [5]. This reduction is attributable to three mechanisms: (1) elimination of control actuator energy consumption across all regulated terminal points; (2) elimination of the over-ventilation energy penalty common in conventionally balanced systems where some zones receive above-design airflow to ensure minimum compliance at the most disadvantaged zone; and (3) reduction of central fan operating pressure requirements resulting from improved system balance.
Compliance and Certification Outcomes
All 499 apartments in the three towers achieved ASHRAE Standard 62.1-compliant ventilation rates under post-commissioning testing, and the development achieved LEED Silver certification including compliance with LEED's Enhanced Indoor Air Quality Strategies prerequisite. New York City Local Law 97 carbon compliance was achieved across all three towers, confirming that the passive ventilation strategy contributed to the building's overall carbon performance within the regulatory framework.
Construction and Commissioning Efficiency
The passive CAR strategy eliminated the need for post-installation ventilation balancing contractor work, which for a 499-apartment, three-tower development would typically represent a significant cost and schedule item. Factory calibration at manufacture ensures that each device is in compliance upon installation, with no field adjustment required. This characteristic was particularly valuable on a three-tower project with staggered construction completion schedules, where electronic balancing systems would have required repeated re-commissioning as each tower came into operation.
Conclusion
The Neptune Towers case study demonstrates that a passive CAR-based ventilation network is a technically viable and economically advantageous alternative to electronically controlled ventilation
balancing for large multi-tower high-rise residential developments. The 25 percent energy waste reduction, LEED Silver certification, and Local Law 97 compliance achieved across 499 apartments and three towers validate the approach as a scalable model for sustainable urban residential HVAC engineering. The elimination of active control infrastructure reduces first cost, eliminates ongoing maintenance and recalibration requirements, and removes a class of potential system failures from the building's operational risk profile.
References
[1] Etheridge, D., & Sandberg, M. (1996). Building Ventilation: Theory and Measurement. John Wiley & Sons.
[2] ASHRAE. (2019). ASHRAE Handbook—HVAC Systems and Equipment, Chapter 46: Variable-Air-Volume Systems. Atlanta, GA: ASHRAE.
[3] eFlow USA. (2022). Technical Data: Constant Airflow Regulators Operating Principles and Specifications. eFlow USA.
[4] Price, A. D., & Akhlaghi, S. (1995). "Thermal comfort and air distribution in mechanically ventilated offices." ASHRAE Transactions, 101(2), 154–168.
[5] eFlow USA. (2023). Case Study: Neptune Towers, 532 Neptune Avenue, Brooklyn NY Passive CAR Ventilation Network. eFlow USA.
[6] NYC Department of Buildings. (2019). Local Law 97 of 2019: Building Emissions Law. New York City, NY: NYC Department of Buildings.
