Typically, not all the kinks are worked out prior to the functional performance testing directed by the commissioning provider. Our testing processes should be paying especially close attention during the transitional periods to identify any instances of unexpected instability, and we should also have a solid understanding of the tools available to the temperature controls contractor to improve performance in such instances. This column, as well as next month’s, details examples of unstable transitions that can occur and how they can be addressed.

Operating Rooms: Occupied vs Unoccupied Modes

Operating rooms are very energy intensive spaces. They require high air changes per hour (ACH), tight temperature and humidity tolerances, and need to consistently remain positively pressurized in relation to adjacent spaces. The high amounts of supply air coming from the serving AHU at a typically low supply air temperature (~48°F) drives up the cooling energy consumed by the AHUs and the fan energy. There is also substantial energy consumed at the supply air valve’s reheat coil to prevent the spaces from being overcooled. A common energy-saving opportunity specified by design engineers is to have an Unoccupied Mode programmed for the space. The space can enter the Unoccupied Mode of operation, which will reduce the supply airflow into the space to save energy, when either of the following scenarios are encountered:

1. The space is scheduled as unoccupied on the BAS. For example, from 6 PM to 6 AM.

2. The space is scheduled as Occupied, but the occupancy sensors in the space have not detected movement for a period of time (e.g. 30 minutes).

The space will need to remain positively pressurized in all scenarios, though. Therefore, as the supply airflow is reduced in Unoccupied Mode, the return airflow is also reduced to always be pulling less airflow out of the space than what is being supplied to it.

On a recent project, prior to testing, we could see through trend review (Figure 2) that the operating room was correctly reducing its supply airflow (and, in turn, the ACH) during the scheduled unoccupied period (the first of two scenarios which would put the space into Unoccupied Mode). Initial review of the trends seemed to indicate occupants entered periodically enough throughout the day that the space never really went into Unoccupied Mode during the scheduled occupied period. However, during functional performance testing, instability in the transition from Occupied Mode operation to Unoccupied Mode operation was identified when trying to verify the system enters Unoccupied Mode in the second scenario listed above.

The system was operating in Occupied Mode, then we exited the space so the occupancy sensor would stop detecting our presence. Once the time delay was realized after the occupancy sensor stopped triggering, the supply airflow setpoint reduced from roughly 2,400 CFM to 800 CFM, and the supply air valve quickly throttled airflow. The return valve tracks at an offset below the measured supply airflow, so there is a delay in how quickly that return valve can respond. This delay in return air valve operation resulted in a brief period of negative space pressure. This negative pressure pulled the inswing door open, which triggered the occupancy sensor, which put the room right back into Occupied Mode! Closer review of the trend data (Figure 2) confirmed the unit never remained in Unoccupied Mode when scheduled occupied. It wasn’t people in and out of the space that kept the occupancy sensor occasionally triggering; it was the system attempting to enter Unoccupied Mode, and the resultant door swinging inward, that was triggering the occupancy sensor. Trend data showed the occupancy sensor momentarily triggers on 30 minute intervals. Without being present just outside the operating room during functional performance testing, this scenario may never have been caught, and the hospital would have paid the excess energy costs for many years to come.

The Fix

The solution to maintain a positive pressure in the operating room while transitioning from Occupied Mode into Unoccupied Mode, and in turn prevent the unstable triggering of the occupancy sensor, was to put a rate limiter on the active supply airflow setpoint for the space. Essentially, the effective supply airflow setpoint would slowly drop from the occupied setpoint (2,400 CFM) to the unoccupied setpoint (800 CFM) over the course of 10 minutes. This allows the return valve to respond quickly enough to the slow drop in measured supply airflow and prevent pulling a negative pressure in the space. Such a rate limiter when going from Unoccupied Mode (800 CFM supply air setpoint) to Occupied Mode (2,400 CFM supply air setpoint) was not needed. An instantaneous step change in the setpoint was tested. The magnitude of the space’s positive pressure went slightly higher than the design team was targeting, but not large enough to prevent staff from entering the space. It was deemed acceptable given the real-world scenarios that would force the space to enter Occupied Mode. We would not want to be slowly walking up the ACH in the space while a surgical team is rushing a patient in for an impromptu surgery, so a rate limiter on how fast the supply airflow setpoint could increase was omitted.

Conclusion

Commissioning providers need to pay extra attention to major operational transitions when testing HVAC systems. That is where instability often occurs. Post additional members of the team either on different computers to review multiple items on the BAS simultaneously, or physically locate additional personnel throughout the building when necessary to allow for all areas of concern to be reviewed at the same time. It is relatively easy to get a system to run well in one mode or another; it is much more difficult getting it to transition between modes stably.
