Federal Energy Grant for Development of Campus Dashboard with Individual Chilled Water, Chiller, and Pump Metering

Project Delivery Method: Design-build (D-B)

Owner Team: College campus management, owner representative (consultant), project manager of capital projects, facility manager, third-party commissioning consultant (CxC), and third-party testing, adjusting, and balancing technician

Project Delivery Team: Design-build (D-B) project manager, utility company representative, and federal energy grant representative

HVAC Project Team: HVAC D-B engineer, automatic temperature control D-B technician, building automation system technician, and energy engineering consultant (EEC)

Application: 2023 ASHRAE Handbook-HVAC Applications: Educational Facilities, Chapter 8; Energy Use and Management, Chapter 37; Owning and Operating Costs, Chapter 38; Building Energy Monitoring, Chapter 42, and Supervisory Control Strategies and Optimization, Chapter 43.

2020 ASHRAE Handbook-HVAC Systems and Equipment: Central Cooling and Heating Plants, Chapter 3; Liquid-Chilling Systems, Chapter 43; Centrifugal Pumps, Chapter 44; and Motors, Motor Controls, and Variable Frequency, Chapter 45.

Project Type: Federal energy grant for development of a campus dashboard with individual chilled water metering, chiller metering, and pump metering (primary-secondary chilled water system), as well as energy dashboard for public view.

References: Refer to the codes and standards located at the back of each ASHRAE Handbook for additional reference.

Other References: ASHRAE Procedures for Commercial Building Energy Audits, ASHRAE Fundamentals of Design & Control of Central Chilled-Water Plants, ASHRAE Standard for Commercial Building Energy Audits, ASHRAE Standard 202 (RE: Commissioning Process for Buildings & Systems), DBIA (Design-Build Institute of America), and ASHRAE Guideline 22-Instrumentation for Monitoring Central Chilled-Water Plant Efficiency.

Click here to see this month’s quiz.

Click here to see the answers to this month’s quiz.

Looking for a reprint of this article?
From high-res PDFs to custom plaques, order your copy today!

Howard McKew is author of Integrated Project Delivery for Building Infrastructure Opportunities for HVAC consultants and mechanical contractors and can be reached at hmckew@bss-consultant.com or at www.buildingsmartsoftware.com.
