Miki Minic knew immediately how to solve the indoor air quality issue at the 227,000-square-foot Miami Class A office complex. The veteran building engineer was in his first week with the global real estate giant, Jones Lang LaSalle (JLL), when he told supervisors he could significantly slash HVAC/R energy use at the 12-story Harbour Centre at Aventura office complex.

Minic had already done so at a 413,000-square-foot office complex across town five years earlier. In fact, he used the results from the previous project to prove his daring claim: he could improve indoor air quality (IAQ), restore cooling capacity and save enough energy in the process to pay for the upgrade inside of a year.

“All of our air handlers were running flat out trying to keep up with our set points,” recalls Minic, chief engineer with Jones Lang LaSalle, which manages the office complex. “Once we measured the static pressure drop across the coil, we knew that the fouled evaporator coil was responsible for our soaring cooling costs and that we could restore HVAC efficiency with the addition of Ultraviolet-C (UV-C) lamps.

In the end, a post-project audit documented a 43.7% increase in one air handler’s airflow levels following the UV-C installation, which also reduced energy use enough to pay for the upgrade in just five-months—an impressive return on investment. The audit showed not only an increase in airflow, but also a 48.3% reduction in pressure drop, indicators that cooling capacity was restored to near original-design specifications. Minic estimates that the addition of UV-C lamps will save the Harbour Centre more than $70,000 in HVAC energy costs each year.

A fact that is sometimes missed, says Minic, is that when you restore cooling capacity by 43%, tenants enjoy their comfort 43% faster. In other words, the fouled coil was taking 43% more time to deliver the same air temperature before the UV-C retrofit than after. Moreover, the germicidal UV-C energy improved coil heat-transfer efficiency to the point where the same temperature could be achieved using just 40% of the previous energy used.



The Use of UV Lighting

The UV-C wavelength has been used extensively since the 1990s to improve IAQ and later to improve heat exchange efficiency, boost airflow and reduce maintenance. The germicidal wavelength eliminates microbial and organic materials buildup on HVAC cooling coils, air filters, duct surfaces and in drain pans.

However, it is the technology’s ability to potentially slash between 10 to 25% of HVAC energy use that drives nine-of-every-10 UV-C installations. According to the U.S. Department of Energy (DOE), Minic is not alone in targeting HVAC/R as a potential source of savings, as this equipment accounts for between 30 to 50% of a building’s total energy use – a figure that may be even more pronounced in southern, humid climates such as Florida.

“There are many benefits of UV-C,” says Minic. “Most important is the improvement to air quality, so tenants enjoy cleaner, healthier air. Absenteeism due to the airborne spread of unsafe microorganisms via HVAC systems is almost eliminated. Moreover, equipment life is improved, downtime and preventive maintenance expenses like cleaning the coils, drain pans, and the purchase of coil and drain treatments, etc., is significantly reduced.”
